compression resistance no more than 350Mpa,in the fields of highway, reservoir, railway, airport and other fields that need rock with cubic shape. It can crush granite, basalt, bluestone, etc the diameters of which are from 100mm to 500mm, and its crushing compression strength is not more than 320Mp. They are ideal choice for crushing and screening.
Working Principle Of Impact Crusher:
The materials are crushed via impact energy produced in the impact crusher. When the materials enter the zone of the board hammer, they are flung into the impact equipments via the high-speed impact of the board hammer. These materials will be re-crushed after rebounding into the scale board. The large materials are crushed into small pieces until it becomes the specified granularities. The end products come out from the base of the impact crusher.
Type |
Spec. |
Feeding Opening (mm) |
Feeding Size (mm) |
Capacity (t/h) |
Power (kw) |
Weight (t) |
PF-1010 |
Φ1000x1050 |
400x1080 |
<300 |
50-90 |
55-75 |
14 |
PF-1210 |
Φ1250x1050 |
400x1080 |
<300 |
70-130 |
110-132 |
17 |
PF-1214 |
Φ1250x1400 |
400x1430 |
<300 |
90-180 |
132-160 |
22 |
PF-1315 |
Φ1320x1500 |
860x1520 |
<350 |
120-250 |
180-260 |
26 |
