Introduction:
YMPJ Disc Wood chipper is mainly used to crush raw wood logs into 1-3cm wood chips, the thickness of last chips is 1.5mm-3mm, length and width is 10-30mm.
It also can cut long bamboo or sugarcane into small chips, the difference between drum chipper is that after crushed by disc wood chipper, the outlet chip dimension is more even.
The disc wood chipper has two feeding type: one is to feed logs from top ,second is to feed from side belt conveyor—changeable speed feeding logs. For outlet discharging chips type , there are two ways , one is the outlet is from the other top door, the other is the outlet is from bottom, both structure and operating are very easy.
It can be driven by both diesel engine and electric motor, very easy to be operated.
Technical Parameter:
|
MODEL
|
YMPJ15-80
|
YMPJ35-160
|
YMPJ-250
|
|
Feeder Size(mm)
|
230*500
|
300*680
|
450*800
|
|
Max Dia infeed (mm)
|
150
|
350
|
450
|
|
Main Power(kw)
|
30
|
55
|
90-110
|
|
Knife (pcs)
|
3
|
6
|
9
|
|
Chips size(mm)
|
10-30
|
10-30
|
10-30
|
|
Capacity(T/H)
|
1-2
|
2-4
|
6-8
|
