XSL Screw Sand Washing Machine
XSL screw stone sand washing machine Application:
The XSL series of grit stone washing and selecting machine is suitable for the washing and selecting, granding, and Screw Sand Washing Machine trash-extracting in industries like metallurgy, construction, water and electricity, etc. Screw Sand Washing Machine is suitable for washing and selecting materials of fine and rough granularity.
XSL screw sand washing machine Features:
1. High level cleaning,reasonable structure;
2. High productivity,small power dissipation;
3. Small loss of sand in the process of sand washing;
4. Much lower malfunction rate
XSL Screw Sand Washing Machine Working principle of spiral washing machine:
The material pours in the from the end of input,the spiral impeller ratates by the driven of the motor and the reducer,and then push the material inside the hopper close to the end of output.Thus,under the action of being advanced,mixed anf the flushing water,the mud wrapped on the material and the impurity go separately.Finally,the separated fine sands are discharged from the discharging port under the advancing movement of the spiral.Thus,the continous work of washing sand is finished again and again.Promptly carries off the impurity and the small proportion foreign matters,and discharge from the overflow port tank washer,completes the cleaning action.The clean sand and crushed stone is carried off by the leaf blade,and ids finally poured into the discharge chute from the revolving impeller,completes the cleaning action.
Washing:
The sand is feeding into the sediment pool from the feeding box, acting by rotating screw blade, the sand is turning and rolling and grinding each other to eliminate impurity and water-air layer around sand to facilitate de-water. The fresh eater rising current from the porous plate carry foreign matter to water surface and overflow the weir plate, to finish washing processing
De-watering:
The sand with bigger density is sunken down to tub bottom, the screw blade push this sand upwards, when passing through upper tub of proper length above water level, the water is draining into sediment pool from another drainage ditch, the de-watered sand is out from the discharging opening.
Classifying:
Material classifying is realized by overflowing the non-needed fines, the controlling method is adjusting height of overflowing weir and adjusting speed of screw.
XSL Screw Sand Washing Machine Working Parameters
| Models |
LSX-920
|
2LSX-920 |
LSX-1120 |
2LSX-1120 |
| Diameter of screw (mm) |
920 |
920 |
1120 |
1120 |
| Length of tub (mm) |
7585 |
7585 |
9750 |
9750 |
| Feed Size (mm) |
≤10 |
≤10 |
≤10 |
≤10 |
| Capacity (t/h) |
100 |
200 |
175 |
350 |
| Speed of screw (r/min) |
21 |
21 |
17 |
17 |
| Electric Motor Power(kW) |
11 |
2x11 |
18.5 |
2x18.5 |
| Water Consumption (t/h) |
10-80 |
20-160 |
20-150 |
40-300 |
| Dimension (mm)(L×B×H) |
8420× 2180 ×3960 |
8420× 3970 ×3960 |
10770× 3950 ×4860 |
10770× 5260 ×4860 |
| Weight (t) |
6.2 |
11.5 |
10.9 |
17.8 |
